Welding results is perfect.
Pulling force test: constant to the joints.
The resistance test: Resistance value is not greater than that of the original wire.
Changes of wire diameter: In order to meet the user’s need for welding the wires of various materials our company can provide the cold welding dies having various kind if inner grooves for users.
Specification
| Model No | AC705 | AC1510-B |
| Product use： | Used for copper, aluminum, gold, silver, nickel, platinum, zinc, tin, tantalum, niobium and other non ferrous metals and their alloy wires’ cold welding. | |
| Welding Size : | Cu: ф1.00-ф4.80mm Al: ф1.00-ф6.80mm |
Cu: ф3.00 mm-ф10.00 mm Al: ф4.00 mm-ф15.00mm |
| Material of product | The body made for Precision casting material | |
| The advantage | Independent hydraulic pump station, safe and reliable, easy to operate and easy to weld. The resistance of the material after welding is turned on, and the material elongation and related physical and chemical indicators remain unchanged. | |
| Dimensions： | 650mmx1000mmx1100mm | 1300mmx730mmx1200mm |
| Motor power | 0.75KW | 2.2KW |
| Recovery Oil pressure | 0.6-1.0Mpa | 0.5Mpa-0.8Mpa |
| Voltage | 380V/50HZ | 380V/50HZ |
| Product Weight | 320KG | 650KG |
